Go Lambdas on Graviton

Contents

I recently had a quick look at how to get Golang Lambdas running on ARM - specifically AWS' Graviton2 processors.

It was quite a trivial process really, and I think there are some price/performance benefits to using ARM.

I referred to the following links:

I started with a simple SAM hello world app, in Go:

$> sam init
Which template source would you like to use?
	1 - AWS Quick Start Templates
	2 - Custom Template Location
Choice: 1

Cloning from https://github.com/aws/aws-sam-cli-app-templates

Choose an AWS Quick Start application template
	1 - Hello World Example
	2 - Multi-step workflow
	3 - Serverless API
	4 - Scheduled task
	5 - Standalone function
	6 - Data processing
	7 - Infrastructure event management
	8 - Machine Learning
Template: 1

 Use the most popular runtime and package type? (Nodejs and zip) [y/N]: n

Which runtime would you like to use?
	1 - dotnet5.0
	2 - dotnetcore3.1
	3 - dotnetcore2.1
	4 - go1.x
	5 - java11
	6 - java8.al2
	7 - java8
	8 - nodejs14.x
	9 - nodejs12.x
	10 - nodejs10.x
	11 - python3.9
	12 - python3.8
	13 - python3.7
	14 - python3.6
	15 - python2.7
	16 - ruby2.7
	17 - ruby2.5
Runtime: 4

What package type would you like to use?
	1 - Zip
	2 - Image
Package type: 1

Based on your selections, the only dependency manager available is mod.
We will proceed copying the template using mod.

Project name [sam-app]: sam-go-graviton

    -----------------------
    Generating application:
    -----------------------
    Name: sam-go-graviton
    Runtime: go1.x
    Architectures: x86_64
    Dependency Manager: mod
    Application Template: hello-world
    Output Directory: .

    Next steps can be found in the README file at ./sam-go-graviton/README.md


    Commands you can use next
    =========================
    [*] Create pipeline: cd sam-go-graviton && sam pipeline init --bootstrap
    [*] Test Function in the Cloud: sam sync --stack-name {stack-name} --watch

Then, I had to modify the template generated to specify the right runtime and architecture. This is slightly odd because Go is treated differently in AWS:

$> cd sam-go-graviton
$> vim template.yml

Update values in the template - here’s the full template, details on updates below:

AWSTemplateFormatVersion: '2010-09-09'
Transform: AWS::Serverless-2016-10-31
Description: >
  sam-go-graviton

  Sample SAM Template for sam-go-graviton

# More info about Globals: https://github.com/awslabs/serverless-application-model/blob/master/docs/globals.rst
Globals:
  Function:
    Timeout: 5

Resources:
  HelloWorldFunction:
    Type: AWS::Serverless::Function # More info about Function Resource: https://github.com/awslabs/serverless-application-model/blob/master/versions/2016-10-31.md#awsserverlessfunction
    Properties:
      CodeUri: hello-world/
      Handler: hello-world
      Runtime: provided.al2
      Architectures:
        - arm64
      Tracing: Active # https://docs.aws.amazon.com/lambda/latest/dg/lambda-x-ray.html
      Events:
        CatchAll:
          Type: Api # More info about API Event Source: https://github.com/awslabs/serverless-application-model/blob/master/versions/2016-10-31.md#api
          Properties:
            Path: /hello
            Method: GET
      Environment: # More info about Env Vars: https://github.com/awslabs/serverless-application-model/blob/master/versions/2016-10-31.md#environment-object
        Variables:
          PARAM1: VALUE
    Metadata:
      BuildMethod: makefile

Outputs:
  # ServerlessRestApi is an implicit API created out of Events key under Serverless::Function
  # Find out more about other implicit resources you can reference within SAM
  # https://github.com/awslabs/serverless-application-model/blob/master/docs/internals/generated_resources.rst#api
  HelloWorldAPI:
    Description: "API Gateway endpoint URL for Prod environment for First Function"
    Value: !Sub "https://${ServerlessRestApi}.execute-api.${AWS::Region}.amazonaws.com/Prod/hello/"
  HelloWorldFunction:
    Description: "First Lambda Function ARN"
    Value: !GetAtt HelloWorldFunction.Arn
  HelloWorldFunctionIamRole:
    Description: "Implicit IAM Role created for Hello World function"
    Value: !GetAtt HelloWorldFunctionRole.Arn

Specifically:

  1. Runtime becomes provided.al2
  2. Architectures becomes arm64
  3. Add Metadata section
Note
Note the indentation change on Metadata! It’s at the same level as Properties.

Then, create the Makefile for the go code:

$> cat hello-world/Makefile
build-HelloWorldFunction:
	GOOS=linux go build -o bootstrap
	cp ./bootstrap $(ARTIFACTS_DIR)/.

Lastly, run the build/deploy:

$> sam build
...
Build Succeeded
...
$> sam deploy --guided

Configuring SAM deploy
======================

	Looking for config file [samconfig.toml] :  Not found

	Setting default arguments for 'sam deploy'
	=========================================
	Stack Name [sam-app]: sam-go-graviton
	AWS Region [eu-west-2]:
	#Shows you resources changes to be deployed and require a 'Y' to initiate deploy
	Confirm changes before deploy [y/N]:
	#SAM needs permission to be able to create roles to connect to the resources in your template
	Allow SAM CLI IAM role creation [Y/n]:
	#Preserves the state of previously provisioned resources when an operation fails
	Disable rollback [y/N]:
	HelloWorldFunction may not have authorization defined, Is this okay? [y/N]: y
	Save arguments to configuration file [Y/n]:
	SAM configuration file [samconfig.toml]:
	SAM configuration environment [default]:

…and so on. Wait for it to finish, then copy the endpoint URL and:

$> curl https://<ENDPOINT>.execute-api.eu-west-2.amazonaws.com/Prod/hello/
Hello, <some ip address>

Et Voila! You’ve just deployed a SAM app running Go, all running on the new Graviton chips!
